DFRobot . SEN0177

<b>Description:</b><br><br>Particle pollution - PM10 and PM2.5 has become a hot issue in recent years. While the term PM is simple, PM itself is a relatively complex mixture with extremely small particles and liquid droplets that float around in the air. Researchers say minute particle pollution as indicated by high PM2.5 readings will cause a spike in the mortality rate of patients suffering heart and lung diseases. As a result public concerns on air quality caused by particle pollution has never ceased growing.This PM2.5 Sensor Module is a digital universal particle density sensor,it can be used to obtain the number of suspended particulate matter in a unit volume of air within 0.3 to 10 microns, namely the density of particulate matter, and outputs via digital interface as well as quality data of per particle. The sensor is useful in a variety of environment-related projects and installations, to provide timely and accurate particle data.<br>DIY Air Purifier with PM2.5 Sensor, Hepa Filter, Fan, Display & Controller<br><BR><BR><b>Specification:</b><br><br>Voltage:4.95 ~ 5.05V<br>Maximum electric current: 120mA<br>Measuring pm diameter:0.3~1.0 1.0~2.5 2.5~10(um)<br>Measuring pm range:0~500 ug/m3<br>Standby Current: ¡Ü200 uA<br>Response time: ¡Ü10 s<br>Operating temperature range:: -20 ~ 50C<br>Operating humidity range: 0 ~ 99% RH<br>Maximum size: 65 x 42 x 23 (mm)<br>MTBF: > = 5 years<BR><BR><b>Shipping List:</b><br><br>PM2.5 Sensor Module - Laser Sensing x1<br>Sensor adapter x1<br>Sensor adapter cable x1

<b>INTRODUCTION</b><br> PM2.5 laser dust sensor is a digital universal particle concentration sensor，it can be used to obtain the number of suspended particulate matter in a unit volume of air within 0.3 to 10 microns, namely the concentration of particulate matter, and output with digital interface, also can output quality data of per particle. The sensors can be embedded in a variety of concentrations of environment-related instruments suspended particulate matter in the air, to provide timely and accurate concentration data. <br> <br> <b>SPECIFICATION</b><br> Voltage: 4.95 ~ 5.05V<br> Maximum electric current: 120mA<br> Measuring pm diameter: 0.3~1.0/1.0~2.5/2.5~10 (um) <br> Measuring pm range: 0~1000 ug/m3<br> Standby Current: ≤200 uA<br> Response time: ≤10 s<br> Operating temperature range: -20 ~ 50C<br> Operating humidity range: 0 ~ 99% RH<br> Maximum size: 46 * 35 * 20mm (1.82 x 1.38 x 0.79 inches) <br> MTBF: > = 5 years<br> <br> <b>SHIPPING LIST</b><br> PM2.5 laser dust sensor x1<br> PM2.5 sensor adapter x1<br> Sensor adapter cable x1<br>
