Square D - LA36175 - Molded Case Circuit Breaker, 3-Pole, 600V 175A, LA Series - Allied Electronics & Automation, part of RS Group

LA36175 - Square D / Schneider Electric - La, 175 Amp, 3 Pole, 600 Volt, Molded Case Circuit Breakers From Square D / Schneider Electric

Square D LA36175 molded case, thermal magnetic; l frame; 240 vac at 50/60 hz, 480 vac star/277 vac at 50/60 hz, 480 vac at 50/60 hz, 600 vac star/347 vac at 50/60 hz, 600 vac at 50/60 hz (ul/csa/nom); 240/415 vac at 50/60 hz (iec); 250 vdc; 175 ampere at 40 deg c; 3 pole

<p>Circuit Breaker, Amps 175, Number of Poles 3, Circuit Breaker Type Standard, AC Voltage Rating 600VAC, DC Voltage Rating 250VDC, For Use With I Line Panelboards, Series LA, Trip Type Thermal Magnetic, Terminal Connection Lug, Max. AIR Rating Not Rated, Phase Connection ABC, Mounting Plug In Panelboard, Height 11.00 In., Width 6.00 In., Depth 5.80 In., Min. Wire Size 1 AWG (Al), Max. Wire Size 600 kcmil (Al), 250 kcmil (Al), Instantaneous Trip Adjustable, High Amp Trip Setting 1750A</p><p><b>Specifications: </b><ul><li>Phase: 3</li><li>Amps: 175</li><li>DC Voltage Rating: 250VDC</li><li>Low Amp Trip Setting: 875A</li><li>Mounting: Plug In Panelboard</li><li>Phase Connection: ABC</li><li>Circuit Breaker Type: Standard</li><li>Width: 6.00"</li><li>Min. Wire Size: 1 AWG (Al)</li><li>Instantaneous Trip: Adjustable</li><li>For Use With: I Line Panelboards</li><li>Height: 11.00"</li><li>AC Voltage Rating: 600VAC</li><li>Max. Wire Size: 600 kcmil (Al), 250 kcmil (Al)</li><li>Depth: 5.80"</li><li>Max. AIR Rating: Not Rated</li><li>Trip Type: Thermal Magnetic</li><li>Item: Circuit Breaker</li><li>Standards: UL listed, CSA certified</li><li>Frame Size: 400A/LA</li><li>Number of Poles: 3</li><li>High Amp Trip Setting: 1750A</li><li>Terminal Connection: Lug</li><li>Series: LA</li></ul></p>
