Square D - HOM215 - MINIATURE CIRCUIT BREAKER 120/240V 15A - RS

Square D Homeline™ Standard 2-Pole miniature circuit breaker is rated at 15 Amps and 120/240 Volt AC at 50/60 Hz. Interrupt rating of this circuit breaker is 10 Kilo-Amps. It measures 2 Inch x 2.98 Inch x 3.13 Inch. This 2-space 1-Phase circuit breaker with clamp terminal connection, accommodates 14 - 8 AWG aluminum/copper wire and 14 - 10 AWG copper wire. It features thermal-magnetic type trip function to ensure reliability. HACR rated circuit breaker supports plug-in mounting. It is perf

Square D 2 Pole 20 Amp Plug on Circuit Breaker Cat: HOM215 Square D Reconditioned

Common Trip, Thermal Magnetic; 2 Pole; 120/240 Vac At 50/60 Hz (Ul/Csa); 15 Ampere; Interrupting Rating 10 Kiloampere; Wire Size 14 To 8 Awg (Aluminum/Copper), (2) 14 To 10 Awg (Copper); Plug On Mounting; Used On Homeline[R] Load Center; Hom Model

Unlike fuses, miniature circuit breakers do not have to be replaced or reset after an overcurrent overload which makes them both more convenient and cost-efficient.<br /><br /> Item: Plug In Circuit Breaker<br /> Amps: 15<br /> Number of Poles: 2<br /> Circuit Breaker Type: Standard<br /> AC Voltage Rating: 120/240VAC<br /> DC Voltage Rating: Not Rated<br /> For Use With: Homeline Load Centers<br /> Series: HOM<br /> Terminal Connection: Screw Clamp<br /> Min. Wire Size: 14 AWG<br /> Max. Wire Size: 8 AWG<br /> Length: 3.13"<br /> Width: 2.00"<br /> Depth: 2.91"<br /> Standards: UL Listed, CSA Certified, HACR<br /> Max. AIR Rating: 10 kA

<p><ul><li>The Square D Homeline 15 Amp 2 Pole Circuit Breaker by Schneider Electric is used for overload and short-circuit protection of your electrical system. This breaker is compatible with Homeline load centers and CSED devices. The ANSI-certified and UL-listed unit is rated for 120VAC and 10,000 AIR. Homeline circuit breakers are built with the same Square D brand quality you have come to expect at a price that makes them the best value in their class. Homeline circuit breakers are the best in class. Designed exclusively for the residential market, Homeline products offer everything you need to distribute electricity throughout your home.<p><b>Specifications: </b><ul><li>Product: Miniature circuit breaker</li><li>Range: Homeline</li><li>Current Rating: 15A</li><li>Certifications: UL listed</li><li>Voltage Rating: 120/240V</li><li>Mounting Type: Plug-in</li><li>Number of Poles: 2P</li><li>Short Circuit Current Rating: 10 kA</li><li>Number of Spaces: 2</li><li>Circuit Breaker Type: Standard</li><li>Ratings: HACR rated</li><li>Electrical Connection: Clamp terminal for 2 cables</li><li>Wire Size: AWG 14...AWG 8 aluminium/copper)1 / AWG 14...AWG 10 copper)2</li><li>Ambient air temperature for operation: 104 F (40 C)</li><li>10,000 AIR</li></ul></p>
