Square D - FA36080 - CIRCUIT BREAKER, MOLDED CASE, FA SERIES, 3-POLE, 600V 80A - Allied Electronics & Automation, part of RS Group

CLASS 650/734/820 I-LINE[R] PANELBOARD/SWITCHBOARD USED ON; UL, CSA APPROVAL; POWER DISTRIBUTION APPLICATION; 240/480/600 VAC AT 50/60 HZ, 480 VAC STAR/277 VAC AT 50/60 HZ, 600 VAC STAR/347 VAC AT 50/60 HZ (UL/CSA/NOM); 415 VAC AT 50/60 HZ (IEC); 250 VDC VOLTAGE RATING; 10/25 KILOAMPERE AT 240 VAC, 18 KILOAMPERE AT 480 VAC STAR/277 VAC OR 480 VAC, 14 KILOAMPERE AT 600 VAC STAR/347 VAC OR 600 VAC (UL/CSA/NOM); 10 KILOAMPERE AT 415 VAC (IEC); 10 KILOAMPERE AT 250 VDC INTERRUPTING RATING; 80 AMPERE CURRENT RATING; 3 POLE(S); 800 TO 1450 AMPERE TRIP SETTING; I-LINE[R] BRAND; FRAME TYPE F; MOUNTING TYPE PLUG ON; TERMINAL WIRE SIZE 12 TO 1/0 AWG (ALUMINUM), 14 TO 1/0 AWG (COPPER); SIZE 4.5 INCH W X 4.13 INCH D X 6 INCH H; TRIPPING METHOD THERMAL MAGNETIC; FA MODEL

Mfr Brand Name: SQUARE D / Catalog No.: FA36080 / Product Name: SQUARE D FA36080 BU 80A 480V 3P USED / Amps: 80 / Volts: 480 / Poles: 3

Square D FA36080 molded case, thermal magnetic; f frame; 240 vac at 50/60 hz, 480 vac star/277 vac at 50/60 hz, 480 vac at 50/60 hz, 600 vac star/347 vac at 50/60 hz, 600 vac at 50/60 hz (ul/csa/nom); 240/415 vac at 50/60 hz (iec); 250 vdc; 80 ampere at 40 deg c; 3 pole

<p>Circuit Breaker, Amps 80, Number of Poles 3, Circuit Breaker Type Standard, AC Voltage Rating 600VAC, DC Voltage Rating 250VDC, For Use With I Line Panelboards, Series FA, Trip Type Thermal Magnetic, Terminal Connection Lug, Max. AIR Rating Not Rated, Phase Connection ABC, Mounting Plug In Panelboard, Height 6.00 In., Width 4.50 In., Depth 4.16 In., Min. Wire Size 14 AWG (Cu), 12 AWG (Al), Max. Wire Size 1/0 AWG, Instantaneous Trip Fixed, High Amp Trip Setting 1450A, Low Amp Trip Setting 800A</p><p><b>Specifications: </b><ul><li>Item: Circuit Breaker</li><li>Height: 6.00"</li><li>Standards: UL Listed, CSA Certified, CE Marked, IEC, Federal Specification W-C-375B/GEN</li><li>Terminal Connection: Lug</li><li>High Amp Trip Setting: 1450A</li><li>Instantaneous Trip: Fixed</li><li>Amps: 80</li><li>DC Voltage Rating: 250VDC</li><li>Depth: 4.16"</li><li>Max. AIR Rating: Not Rated</li><li>Mounting: Plug In Panelboard</li><li>Phase: 3</li><li>Low Amp Trip Setting: 800A</li><li>Frame Size: 100A/FA</li><li>Max. Wire Size: 1/0 AWG</li><li>Circuit Breaker Type: Standard</li><li>Number of Poles: 3</li><li>For Use With: I Line Panelboards</li><li>Series: FA</li><li>Phase Connection: ABC</li><li>AC Voltage Rating: 600VAC</li><li>Width: 4.50"</li><li>Min. Wire Size: 14 AWG (Cu), 12 AWG (Al)</li><li>Trip Type: Thermal Magnetic</li></ul></p>

FA36080 - Square D / Schneider Electric - Fa, 80 Amp, 3 Pole, 600 Volt, Molded Case Circuit Breakers From Square D / Schneider Electric
