Safety switch, Telemecanique Safety switches XCS, plastic XCSLE, 4NC+2 NO, slow break, 3 entries tapped M20 -230 V | Mayer Electric

SQUARE D . SQDXCSLE3737342

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerSQUARE D
Attribute00230 V - 15...10 %
Attribute012 NC + 1 NO
Attribute02Telemecanique Safety switches XCS
Attribute033 entries tapped M20 x 1.5
Attribute04spring terminal 1 x 1.5 mm? flexible or solid cable || spring terminal 2 x 0.5 mm? flexible cables with 13 mm bared ends
Attribute05with interlocking, locking by solenoid
Attribute06slow-break, break before make
Attribute07for actuator withdrawn 1 LED (orange) || for actuator inserted and locked 1 LED (green)
Attribute082 NC + 1 NO slow-break, break before make)
Attribute09locking on de-energisation and unlocking on energisation of solenoid
Attribute10safety switch
Attribute11230 V
Attribute12XCSLE
Attribute137-13 mm
Attribute14plastic
Attribute15slim
Attribute163
Attribute17key operated turret head
Attribute1818 months
Attribute1910 mA at 20 ?C
Attribute20205-205 mm
Attribute2110 cyc/mn for maximum durability
Attribute22300 VUL 508 || 300 VCSA C22.2 No 14 || 250 V 3)EN/IEC 60947-1
Attribute234 A cartridge fuse gG (gl) || 6 A fast blow
Attribute24double insulated
Attribute25with NC contact
Attribute26, moq, multiple, tierMinQty11
Attribute270.01 m/s
Attribute280.55 A 24 V, DC-13, R300 EN/IEC 60947-5-1 || 0.75 A 240 V, AC-15, C300 EN/IEC 60947-5-1
Attribute2920 N
Attribute301000000 cycles
Attribute310.5 m/s
Attribute32, Attribute38PA (polyamide)
Attribute334 A
Attribute34B10d = 5500000 value given for a life time of 20 years limited by mechanical or contact wear
Attribute35AC/DC
Attribute3644 mm
Attribute3751 mm
Attribute39AC
Attribute4017 V
Attribute411400 N
Attribute421.2 J against the partition || 4.9 J without partition
Attribute430.53 kg
Attribute444 kV EN/IEC 60947-5-1
Attribute4550/60 Hz
Attribute46can reach category 4 with the appropriate monitoring system and correctly wired EN/ISO 13849-1 || can reach PL = e with the appropriate monitoring system and correctly wired EN/ISO 13849-1 || can reach SIL 3 EN/IEC 61508
Attribute47ENVEOLI110902EN
Attribute48, Attribute49Yes
Attribute50ENVPEP110915EN
Attribute51Green Premium product
Attribute52Pro-active compliance (Product out of EU RoHS legal scope)
Attribute53Reference contains Substances of Very High Concern above the threshold
Attribute54Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Attribute55T?V || UL || CSA
Attribute56-25-60 ?C
Attribute57-40-70 ?C
Attribute58EN/IEC 62061 || EN/IEC 60947-5-1 || EN/ISO 13849-1 || CSA C22.2 No 14 || EN 1088/ISO 14119 || EN/IEC 60204-1 || UL 508
Attribute59class II EN/IEC 61140
Attribute6010 gn 11 ms IEC 60068-2-27
Attribute615 gn 10-500 Hz)IEC 60068-2-6
Attribute62TC
Attribute63IP66 conforming to EN/IEC 60529 and EN/IEC 60947-5-1 || IP67
AttributeKey00[Us] Rated Supply Voltage
AttributeKey01Contacts Type And Composition
AttributeKey02Range Of Product
AttributeKey03Cable Entry
AttributeKey04Electrical Connection
AttributeKey05Locking Options Description
AttributeKey06Contact Operation
AttributeKey07Local Signalling
AttributeKey08Solenoid Contacts Type And Composition
AttributeKey09Electromagnet Interlocking
AttributeKey10Product Or Component Type
AttributeKey11Signalling Circuit Voltage
AttributeKey12Component Name
AttributeKey13Cable Outer Diameter
AttributeKey14Material
AttributeKey15Design
AttributeKey16Number Of Poles
AttributeKey17Head Type
AttributeKey18Warranty
AttributeKey19Minimum Switching Current
AttributeKey20, height_AttribHeight
AttributeKey21Maximum Operating Rate
AttributeKey22[Ui] Rated Insulation Voltage
AttributeKey23Short-Circuit Protection
AttributeKey24Insulation
AttributeKey25Positive Opening
AttributeKey26Load Factor
AttributeKey27Minimum Actuation Speed
AttributeKey28[Ie] Rated Operational Current
AttributeKey29Minimum Actuator Force For Extraction
AttributeKey30Mechanical Durability
AttributeKey31Maximum Actuation Speed
AttributeKey32Body Material
AttributeKey33[Ithe] Conventional Enclosed Thermal Current
AttributeKey34Safety Reliability Data
AttributeKey35Supply Voltage Type
AttributeKey36, width_AttribWidth
AttributeKey37, length_AttribDepth
AttributeKey38Head Material
AttributeKey39Signalling Circuit Type
AttributeKey40Minimum Switching Voltage
AttributeKey41Maximum Actuator Forcible Withdrawal Rtc
AttributeKey42Resistance To Mechanical Impact
AttributeKey43, Weight_AttribNet Weight
AttributeKey44[Uimp] Rated Impulse Withstand Voltage
AttributeKey45Supply Frequency
AttributeKey46Safety Level
AttributeKey47Circularity Profile
AttributeKey48Rohs Exemption Information
AttributeKey49Mercury Free
AttributeKey50Environmental Disclosure
AttributeKey51Sustainable Offer Status
AttributeKey52Eu Rohs Directive
AttributeKey53Reach Regulation
AttributeKey54California Proposition 65 : WARNING: This product can expose you to chemicals including
AttributeKey55Product Certifications
AttributeKey56Ambient Air Temperature For Operation
AttributeKey57Ambient Air Temperature For Storage
AttributeKey58Standards
AttributeKey59Electrical Shock Protection Class
AttributeKey60Shock Resistance
AttributeKey61Vibration Resistance
AttributeKey62Protective Treatment
AttributeKey63Ip Degree Of Protection
DimensionUnitmm
Extra Product NameSafety switch, Telemecanique Safety switches XCS, plastic XCSLE, 4NC+2 NO, slow break, 3 entries tapped M20 -230 V | Mayer Electric
UPC3606489413767
Weight0.53
WeightUnitkg
depth, length51.0
height410.0
jsonUrlData/Product/SQUARE-D-Safety-switch-Telemecanique-Safety-switches-XCS-plastic-XCSLE-4NC2-NO-slow-break-3-entries-tapped-M20-230-V-3606489413767
jsonUrlData2f8d624c9-0f32-4a1f-83be-aeea0058513a
MPN, SKUSQDXCSLE3737342
qtyInStock0
tierPrice1507.73
width44.0

Distributor offers

SellerSKUMOQIn stockMultiplePrices
mayerelectric.comSQDXCSLE3737342111 @ $507.73
