00309ET3E215T-W22 MOTOR 3HP 8P 213/5T WFF2 from WEG ELECTRIC CORP
Gallery
Attributes
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| kscdirect.com | WEG 00309ET3E215T-W22 | 1 | 1 | 1 @ $1624.26 | |
| industrialmotors.com | 00309ET3E215T-W22 | 1 | 1 | ||
| 00309ET3E215T-W22 | 1 | -2 | 1 | 1 @ $1737.94 | |
| 00309ET3E215T-W22 | 1 | Ships From Manufacturer | 1 | 1 @ $1791.78 | |
| 00309ET3E215T-W22 | 1 | 1 | 1 @ $1586.25 | ||
| Square One | 00309ET3E215T-W22 | 1 | 1 | ||
 midwestapplianceparts.com | 00309ET3E215T-W22-WG-P | 1 | Current Unavailable - No ETA Available | 1 | 1 @ $1496.38 |
 vfds.com | 00309ET3E215T-W22 | 1 | 1 | 1 @ $2115.00 | |
| AE7TVA | 1 | 1 | 1 @ $2764.00 | ||
| WWG6AJA6 | 1 | 1 | |||
| 00309ET3E215T-W22-WEG | 1 | 1 | 1 @ $1861.20 | ||
 MRO Supply | 1312169 | 1 | 1 | 1 @ $1618.43 | |
 Walker Industrial | 00309ET3E215T-W22 | 1 | 3 to 5 Days | 1 | 1 @ $1586.25 |
| sustainablesupply.com | C1566480 | 1 | Add to Cart | 1 | 1 @ $2241.34 |
 Zoro | G0812594 | 1 | 5 | 1 | 1 @ $1719.00 |
 National Supply Network | B873441 | 1 | -2 | 1 | 1 @ $2617.20 |
 Radwell | 00309ET3E215T-W22 | 1 | 1 | ||
| Applied Industrial | 101388279 | 1 | 1 | ||
| 00309ET3E215T-W22 | 1 | -2 | 1 | 1 @ $2347.66 | |
 electricmotorwholesale.com | 00309ET3E215T-W22 | 1 | 1 | 1 @ $1184.00 |
Related on Amazon
As an Amazon Associate, we earn from qualifying purchases. (paid link) CERTAIN CONTENT THAT APPEARS ON THIS SITE COMES FROM AMAZON. THIS CONTENT IS PROVIDED 'AS IS' AND IS SUBJECT TO CHANGE OR REMOVAL AT ANY TIME.
WEG 00309ET3E215T-W22 W22 NEMA Premium Efficiency Ball Bearing Severe Duty and General Purpose Electric Motor, 3 HP, 3-Phase, 865 rpm, 208-230/460 V, 60 Hz, Frame 213/5T
Brand: WEG
Details
- Current Rating 10.1-9.12/4.56 A
- Totally Enclosed Fan Cooled - TEFC (IP55) water tight and dust tight enclosure
- Squirrel cage rotor / Aluminum die cast
- Ball bearings are supplied as standard
- Class "F" (?T = 80K) insulation for all frames
Listing
| Binding | Misc. |
|---|---|
| Product group | BISS Basic |
| Product type | ELECTRIC_MOTOR |
| Model | 1403804 |
| Part number | 00309ET3E215T-W22 |
| Items per pack | 1 |
| Label | WEG |
| Manufacturer | WEG |
Catalog
| Feature | Current Rating 10.1-9.12/4.56 A |
|---|---|
| Category | Tools & Home Improvement |
| MPN | 00309ET3E215T-W22 |
| Product group | BISS |
| Product type | BEARINGS_AND_BUSHINGS |
| Manufacturer | WEG |
WEG Mtr,3 Ph,3 HP,865,230/460V,Eff 85.5 (00309ET3E215T-W22)
Brand: WEG
Listing
| Binding | Misc. |
|---|---|
| Product group | BISS Basic |
| Product type | ELECTRIC_MOTOR |
| Part number | 00309ET3E215T-W22 |
| Items per pack | 1 |
| Label | WEG |
| Manufacturer | WEG |
Weg 3 HP General Purpose Motor, 3-Phase, 865 Nameplate RPM, Voltage 208-230/460, Frame 215T - 00309ET3E215T-W22
Brand: WEG
<p><b>Specifications: </b><ul><li>Item:-General Purpose Motor</li><li>Motor Application:-General Application</li><li>Motor Design:-3-Phase</li><li>Motor Enclosure Design:-Totally Enclosed Fan-Cooled</li><li>HP:-3</li><li>Nameplate RPM:-865</li><li>Frame:-215T</li><li>Voltage:-208-230/460</li><li>Hz:-60</li><li>Phase:-3</li><li>Full Load Amps:-10.1-9.12/4.56</li><li>Number of Speeds:-1</li><li>Mounting:-Base</li><li>Motor Mounting Position:-Horizontal</li><li>Motor Thermal Protection:-None</li><li>Insulation Class:-F</li><li>Service Factor:-1.25</li><li>Bearings:-Ball</li><li>Frame Material:-Cast Iron</li><li>Max. Ambient Temp.:-40 Degrees C</li><li>Rotation:-CW/CCW</li><li>Shaft Dia.:-1-3/8"</li><li>Shaft Length:-3-3/8"</li><li>Length Less Shaft:-16-1/8"</li><li>Overall Length:-19-1/2"</li><li>Motor Shaft Design:-Keyed</li><li>RPM Range:-Under 1000</li><li>Standards:-UL, CSA, CE, NOM, NEMA Class 1, Div 2, Groups B, C & D</li><li>Duty:-Continuous</li><li>Efficiency Group:-High Efficiency and NEMA Premium(R)</li><li>Nominal Efficiency:-85.5%</li><li>Warranty (Years):-3</li><li>RPM Group:-Under 1000</li><li>UNSPSC:-26101612</li></ul></p>
Details
- Item:-General Purpose Motor
- Motor Application:-General Application
- Motor Design:-3-Phase
- Motor Enclosure Design:-Totally Enclosed Fan-Cooled
- HP:-3
Listing
| Product group | Home Improvement |
|---|---|
| Product type | ELECTRIC_MOTOR |
| Part number | 00309ET3E215T-W22 |
| Label | Weg |
| Manufacturer | Weg |
