| Actuator Color | Natural |
| Actuator Material | Nylon |
| Actuator Style | Flush, Side |
| Actuator Travel | 2.79 mm [ .11 in ] |
| Configuration (Pole-Throw) | Four Pole - Double Throw |
| Contact Base Material | Copper Alloy |
| Contact Current Rating (A) | 0.3 |
| Contact Plating | Silver |
| Grade | Telecom |
| Length | 10.16 mm [ .4 in ] |
| Mounting Angle | Right Angle |
| Mounting Type | Surface Mount |
| Number of Actuators | Single |
| Number of Positions | 4 |
| PCB Mount Retention, Threaded Case | Without |
| Product Type | Switch |
| Stamped Marking | With |
| Switch Style | Auto-Insertable |
| Switch Type | Slide |
| Terminal Configuration | Standard |
| Termination Type | PC |
| UL Flammability Rating | UL 94V-0 |
| Width | 7.35 mm [ .29 in ] |
