Attributes
| Key ^ | Value |
|---|---|
| AC Voltage Rating | 480VAC |
| Amps | 50 |
| Circuit Breaker Type | Standard |
| Country of Origin (subject to change) | Mexico |
| DC Voltage Rating | 250VDC |
| Depth | 4.16" |
| For Use With | I Line Panelboards |
| Frame Size | 100A/FA |
| Height | 6.00" |
| High Amp Trip Setting | 850A |
| Instantaneous Trip | Fixed |
| Item | Circuit Breaker |
| Low Amp Trip Setting | 400A |
| Max. AIR Rating | Not Rated |
| Max. Wire Size | 1/0 AWG |
| Min. Wire Size | 14 AWG (Cu), 12 AWG (Al) |
| Mounting | Plug In Panelboard |
| Number of Poles | 2 |
| Phase | 1 |
| Phase Connection | AB |
| Series | FA |
| Standards | UL Listed, CSA Certified, CE Marked, IEC, Federal Specification W-C-375B/GEN |
| Terminal Connection | Lug |
| Trip Type | Thermal Magnetic |
| Width | 3.00" |
