| B1 Shaft Penetration | 14.9 mm |
| Bore Dia. | 7 mm |
| Bore Tolerance | +0.05 mm / +0.01 mm |
| Country of Origin (subject to change) | Germany |
| Fastening Dimensions, Measurement Type | Metric |
| Finish | Clear Anodized |
| Hub Width | 10.0 mm |
| Material | Aluminum |
| Max. RPM | 15000 RPM |
| Max. Temp. Range (F) | -22?F to 175?F (-30?C to 79?C) |
| Number of Screws | 1 ea |
| Outside Dia. | 1.457 in (37.0 mm) |
| Overall Length | 1.181 in (30.0 mm) |
| Recommended Shaft Tolerance | +0.0000 in / -0.0005 in |
| Screw Finish | Black Oxide |
| Screw Material | Alloy Steel |
| Screw Seating Torque | 3.0 Nm |
| Screw Type, Style | Clamp |
| Set Screw Size | M4 |
| Weight | 0.0573 lbs |
